Whyte T-160 S V1 Bike

New for MY21, the T-160 takes the race-winning pace and exquisitely balanced handling from the benchmark S-150 29er
and turns it up to 11 – perfect for today and tomorrow’s progressive trail rider.

Combining Whyte’s proven OTO geometry with an all-new alloy frame and 150mm of super-refined rear suspension travel,
the T-160 promises extended All Mountain capabilities with exceptional speed, control and balance on technical
trails.

Shimano 4 piston brakes combined with RockShox suspension gives the new T-160 S total control on every trail you
throw it down.

Specifications

Frame and Forks

• Frame: 6061 Alloy, SCR Aluminium Front Triangle with Tapered Head Tube and Intergrip Seat Clamp System, ISCG, 2
  Guide Mounts, Alloy Symmetrical SCR Rear Triangle, 148mm Boost Dropouts
• Fork: RockShox Lyrik Select RC 29″, 160mm Travel, 42mm Offset, DebonAir, Charger RC Damper, Fast Black Coating,
  Tapered Steerer, 110mm x 15mm Boost, Maxle Ultimate
• Rear Shock: RockShox Deluxe Select + RT, DebonAir, Fast Black Coating, Adjustable Rebound and 2 Position
  Compression
• Headset: FSA No. 57E Orbit ZS, 1 1/2″ Lower and 1 1/8″ Upper Sealed Cartridge Bearings

Drivetrain

• Rear Derailleur: Shimano SLX RD-M7100, Shadow Plus, 12 Speed
• Cassette: Shimano SLX M7100, 10-51 Tooth, 12 Speed
• Chain: Shimano SLX M7100, 12 Speed
• Crankset: Shimano FC-MT610, 32 Tooth, Hollow Tech 2, 170mm, Boost 12 Speed
• Bottom Bracket: Shimano MT800, BSA, 73mm

Braking/Shifting

• Front Brakes: Shimano BR-MT420, 4 Piston with Metal Pads, 203mm Disc, Internal Routing
• Rear Brakes: Shimano BR-MT420, 4 Piston with Metal Pads, 203mm Disc, Internal Routing
• Brake Levers: Shimano BL-M4100, I-Spec EV
• Shift Levers: Shimano SLX M7100, 12 Speed

Wheels

• Rims: WTB ST i30 TCS 2.0 System, Pinned Joint, Tubeless Ready, 32 Hole
• Front Hub: Shimano MT410-B, Centre-lock, 15 x 110mm Boost Through Axle, 32 Hole
• Rear Hub: Shimano MT410-B, Centre-lock, Micro Spline, 12 x 148mm Boost Through Axle, 32 Hole
• Spokes: DT Swiss Champion 2.0mm, Black Stainless, Brass Nipples
• Tyres: Maxxis High Roller II TR 29” x 2.5” WT 60TPI, EXO Sidewall Protection, 3C Maxx Terra, Front, Maxxis
  Dissector TR 29” x 2.4” WT 60TPI, EXO Sidewall Protection, Dual Compound, Rear

Finishing Kit

• Seatpost: Whyte drop.it Post II Adjust, 30.9mm, Medium / Large 140-170mm Travel, X-Large 170-200mm Travel, Shimano Remote Lever
• Saddle: Whyte Custom, Dual Density, Triple Panel Design
• Handlebar: Whyte Custom 6061 Alloy, 30mm Rise, 31.8mm, 780mm Wide
• Stem: Whyte Gravity Stem, 35mm Extension
• Grips: Whyte Lock-on V Grip
• Pedals: None
